Function introduction

5 x 8 dot matrix possible

Low power operation support:

4.75to 5.25V

Liquid crystal drive waveform

A (One line frequency AC waveform)

4-bit or 8-bit MPU interface enabled

80 x 8-bit display RAM (80 characters max.)

9,920-bit character generator ROM for a total of240 character fonts

208 character fonts (5 x 8 dot)

32 character fonts (5 x 10 dot)

DISPLAY TYPE

POLARIZER

STN,YELLOW-GREEN, POSITIVE

TRANSFLECTIVE

Applicable LCD duty 1/166 bias 1/5

-20℃ ~+70°COperating Temperature

Storage Temperature

-30℃~+80℃

VIEWING DIRECTION6.0’CLOCK，

BACKLIGHT:

Controller

YELLOW-GREEN

ST7066U

If the YOU needs to do other display mode: such as STN Blue TRANSMISSIVE Or FSTNPOSITIVE TRANSFLECTIVE/如您有需要，也可做其它显示模式:如STN蓝膜全透,FSTN正显半透
